Voltage(V) | 12V |
IP rating | IP65 |
No-load current(A) | ≤0.07A | 5~40(℃) | |
Load current(A) | ≤0.25A | Storage temperature(℃) | 5~40(℃) |
Max. power(W) | 5W | Noise on load (dB) | 65dB |
Material of outer tube | 6063Aluminium | Backlash (mm) | ≤0.4 |
Material of lead screw | Trapezoid,Steel | Colour | Black |
Material of piston rod | 304 stainless steel | Certification | CE |
Material of the nut | Plastic | Wire connection | Bare wire/4 pins connector |
Working duty(S2) | Work 2 minutes and rest 18 minutes | End mounting | O type |
Life time(cycles) | ≥10K | Wire length(m) | 0.5 |
